Parts

Rod eyescut from heavy-wall tubing welded to pre-chromed barstock.

Standard flanges and stubs welded to bent-to-order tubing. Reduced inventory, improved delivery. Lower piece shows result of 21,000 psi (144,790

Tubing welded to end cap. Parts welded to cylinder body.

Barstock welded to clevis forging for manufacture of large (5 inches (127 mm) diameter and larger) piston rods

Four welds to complete assembly.
